Archive for April 2022

Change Video Card

Question: I've been running my hackintosh for 3+ years. I've been perfectly content with it, BUT if I wanted/needed to change vidcards could I just plug and play it. I'm running:

High Sierra Clover GTX 960 i5 7400

I use it for audio production with Logic. I have my NVMe, and also a backup of it on a smaller ssd (original install disk)

submitted by /u/T0xAvenja
[link] [comments]

Anyone tried this method to have the RX 6600 working on CATALINA? Details included

What I am posting below is some interesting info from a thread that is currently trying to get the AMD Vega 8 IGPU working on Mac OS. However a poster did share this info.

"So I made two discoveries recently with regards to hardware acceleration. Not sure if some of you know but what I found that's interesting is both AMD and Intel kexts in macOS /S/L/E I found share the same IOMatchCategory values under the kexts which is IOAcceleration. Unique to Intel is the IntelAccelerator IOClass which can be found in the AppleIntelSKLGraphics and AppleIntelICLGraphics kexts. I am quite sure with the info we've found so far it is possible to create a SSDT or even kext driver of sorts. We just need to figure out how to designate the AMD Vega properly as an internal IGPU.

Secondly (on a fairly related note of injecting AMD codes for acceleration), I managed to recently successfully boot up a RX6600 card in a Z590 system under Catalina. As we know the RX6600 isn't supported until Monterey, but I managed to fill in the required gaps in the Apple AMD kexts (AMDRadeonX6000Controller and AMDFramebuffer) by adding a Navi 23 class and the RX6600 device-id. I was totally amazed it booted up. This means it is totally possible to add the Vega 8 for acceleration.

Alright, that's good going - it might work for my Atari VCS. And thanks for the explanation about the IOAcceleration.

With regards to the RX6600 Catalina solution, well this is what I did:

-Made an external USB SSD install of Catalina. Disabled SIP from Recovery mode and Gatekeeper for both Monterey and Catalina (from separate installs).

Made a copy of the following Catalina kext files onto Catalina Desktop, plus from Monterey Beta in separate folder:

AMDRadeonX6000.kext

AMDRadeonX6000Framebuffer.kext

AMDRadeonX6000HWServices.kext

Reading the equivalent Monterey files, edited the Info.plist of Catalina kext files by transferring over missing sections of the AMD Info.plist (cutting and pasting) in the kexts, with particular regards to the Navi23 IOKitPersonality details and then added the FF731002 device-id to the end of it under IOPCIMatch. Saved the edited Info.plists.

Copied the files over into S/L/E, renabled Gatekeeper and SIP and then rebooted with RX6600.

submitted by /u/Jotoku
[link] [comments]

Do I need to Upgrade anything?

I would like to switch to hackintosh just want to know if I should upgrade anything to atleast run it.

Pretty sure I can run High Sierra 10.13.6

HP Pavilion 15-bc5xxx

MOTHERBOARD: HP 8640

CPU: Intel Core i5-9300H 4100mhz

GPU: Nvidia GTX 1050

GPU 2:Intel UHD 630

RAM: 8GB 1333mhz

SSD: SAMSUNG MZVLB512HAJQ-000H1 477GB

WIFI: Realtek RTL8822BE 802.11ac PCIe Adapter (I use ethernet mainly though)

DISPLAY: 1920 x 1080 60Hz

DISPLAY 2: 1920 x 1080 60Hz

If you need anything else lmk

submitted by /u/RedNightBlood
[link] [comments]

When I'm downloading something, or listening to music via spotify, I'm unable to connect to websites?

I'm currently running my Optiplex 3020 as a Monterey hackintosh, smbios as a macmini7,1. My internet kext is - RealtekRTL8111. Using the built-in ethernet port. Everything seems to work fine, but I have this annoying issue.

Whenever I'm downloading something or listening to Spotify, or sometimes if I even have a YT video in the background, I'll constantly get the "site is unreachable please check your internet" error. I'm not 100% sure this is my Optiplex, or my router, but it doesn't happen on other devices. and I'm able to still connect to my router's admin panel while websites won't load. I also have Windows 10 on this machine and it doesn't seem to happen when using it. I had Big Sur on this machine before but I can't really remember if it had the same issue or not.

I'm using OC 0.8.0 if that matters.

Not sure what else to include, but does anyone have any experience with this? Is it possible to fix?

I also keep seeing "volume hash mismatch" once in awhile, telling me to reinstall macos. But I'm not sure what that error means because the system is stable, aside from my internet. I've heard this is a bug with the latest version of Monterey, but could this have something to do with it? I've never experienced any kernel panics, crashes, apps malfunctioning, etc.

submitted by /u/LeLoyon
[link] [comments]

M73 Haswell Catalina stuck AmiShimTimerBoostExit changed current period

Good day, peeps. I've been stuck at this line this past few days. I'm trying to install Catalina. I have tried all usb ports on the device, and enabled/disbaled DevirtualiseMmio, EnableWriteUnprotector, SetupVirtualMap, SyncRuntimePermissions to no avail. Hoping someone could help me out.

​ Stuck @ AmiShimTimerBoostExit changed current period to 549254 ​ config.plist: https://www.mediafire.com/file/4gger4t4iznvmuc/config.plist/file ​ Logs: https://pastebin.com/YPNvB5hp ​ Specs: CPU Intel(R) Core(TM) i3-4150T CPU @ 3.00GHz Memory 2x4GB Samsung DDR3 1600MHz (PN: M471B5173DB0-YK0) GPU Intel HD Graphics 4400 Storage WDC WDS120G2G0A-00JH30 Audio Realtek ALC283 Ethernet Intel I217V OpenCore 0.8.0-DEBUG SMBIOS iMac14,4 ​ USB Tree: ├───BOOT │ .contentFlavour │ BOOTx64.efi └───OC │ .contentFlavour │ config.plist │ OpenCore.efi ├───ACPI │ SSDT-EC-DESKTOP.aml │ SSDT-PLUG-DRTNIA.aml ├───Drivers │ OpenRuntime.efi │ HfsPlus.efi ├───Kexts │ ├───AppleALC.kext │ │
│ ├───IntelMausi.kext │ │
│ ├───Lilu.kext │ │
│ ├───SMCProcessor.kext │ │
│ ├───SMCSuperIO.kext │ │
│ ├───VirtualSMC.kext │ │
│ └───WhateverGreen.kext │
├───Resources │ ├───Audio │ ├───Font │ ├───Image │ └───Label └───Tools OpenShell.efi

submitted by /u/sierra_nine
[link] [comments]

BigSur on Acer Predator G5900

Hey there,

i'm trying for two day's now too install BigSur with OC 0.8.0. Getting no issues to boot the install page right now, that's how far i got on my own :crazy:. This ist my first time trying with OpenCore and my last attempt i tried Hackintosh is year's back. So i followed up the stepps from Dorotias Guide - Desktop Lynnfield and Clarkdale - and create my config.plist, got the necessary files like SSDT-EC-DESKTOP.aml. After some stuck's and fixing as i said, i got stuck at the...

Read more

Author: emre71

Update from Catalina to Big Sur

Hi i want to upgrade my hackintosh from mac os Catalina to Big Sur, and this is my first time doing a major software upgrade on an open core hackintosh. Catalina works mostly good, aside from iGPU issues (dissabled it) and turboboost causing freezes (solved turning it off).

Should I update directly from catalina? Or would be a better idea to take the time and do all the hackintosh from the ground up specially for big sur?

Hardware: Intel core i9 10850K Gigabyte Vision G Z490 Amd RX 580 8GB 32 GB Ram 3200MHz Nvme SSD for hackintosh Sata SSD with a working Catalina system Nvme SSD for FCP Fenvi T919

submitted by /u/andres_da
[link] [comments]

Has anyone tested BigSurface kext?

I'm wondering if there's someone who has already installed this kext and if it works as promised. I would like to know if this will work or if someone has tested it on a Surface Laptop 3 as well. I did try it but ended messing some things around up that I needed to paste a backup of EFI folder.

Thank you in advance!

submitted by /u/dauryfco
[link] [comments]

Overclocking on MacOS

I am looking to overclocking my 6600xt on macOs, but all amd software seems to be windows only, is there a work around?

submitted by /u/Entire-Ad-737
[link] [comments]

Added an internal HDD to dual boot hackintosh; works on win10, not on mojave

I have a fully working desktop hackintosh that has ethernet, working usb ports that recognise external drives etc. I added a 500gig hdd to my system on one of the sata ports. The drive shows up in win10 and I have moved files into it ,to use as data disk. But when I boot into Mojave, I don't even see it listed under ''All volumes and devices".

The added drive is GPT, formatted into exFAT and NTFS partitions. Using opencore. Opencore doesn't list the hdd during bootmenu as there is no EFI partition on the 500 gig drive.

Thanks for any help !

submitted by /u/meanagray
[link] [comments]

Help with Big Sur and Broadcom Bluetooth Dongle?

I have an IOGear GBU521 USB Bluetooth Dongle.

It shows up in System Report as: BCM920702 Bluetooth 4.0

EDIT: I've found the solution, thanks to a little more googling and the good folks at Acidanthera. I'm leaving this post up, though, in case anybody has the same dongle and is having trouble.

According to the long details on this page, Big Sur users need to use BlueToolFixup.kext instead of BrcmBluetoothInjector.kext. So I removed the unnecessary AirportBrcmFixup.kext, kept BrcmFirmwareData.kext and BrcmPatchRAM3, and swapped in BlueToolFixup instead of BrcmBluetoothInjector, did a Clean Snapshot in ProperTree, and now everything's working great.

(The rest of my original post is below)

It used to work fine in Monterey but I guess Big Sur broke something with Broadcom bluetooth stuff.

I've been trying to follow the Broadcom WiFi and Bluetooth Kext instructions from the Dortania Install Guide, but I'm not having any luck.

Do I need to install both the AirportBrcmFixup and BrcmPatchRAM kexts? Or is one for Wifi and the other for Bluetooth?

When I install just the BrcmPatchRAM kexts (BrcmBluetoothInjector, BrcmFirmwareData, BrcmPatchRAM3) and run an OC Clean Snapshot, the computer hangs at boot. It continually shows an error saying it's refusing a core dump, and refers specifically to my BCM920702 Bluetooth 4.0.

If I also install the AirportBrcmFixup.kext and do a Clean Snapshot then it boots OK, but still won't allow me to turn on bluetooth.

I have a suspicion that it's an error in the loading order for my kexts. If I don't use AirportBrcmFixup.kext, Propertree puts the three Brcm* kexts in order at the top. If I do include AirportBrcmFixup, propertree puts just BrcmBluetoothInjector and BrcmFirmwareData at the top, AirportBrcmFixup later in the list, and seems to leave out BrcmPatchRAM3 entirely.

It just seems odd to me that ProperTree puts the three Brcm* kexts above Lilu. That can't be right, can it?

submitted by /u/TheBigMaestro
[link] [comments]

Intel NUC11 and 11th Gen CPU

Hello, I'm experimenting with Big Sur for "Nuc 11". It works with the attached "EFI", but the mouse and keyboard do not work

Author: endera

Can’t get usb 3.0 speeds on Asrock z490 pro 4 MOB

Hey guys I just updated to Opencore 0.8.0 and my usb 3 went out.

Ive tried remapping my USB ports and messing with bios settings. Nothing seems to work. When I use USBInjectall kext, I get the usb3 speeds but not with my usb map kext.

Anyone have any suggestions? Thank you!

Specs: MOB: asrock z490 pro 4 Cpu:Intel 10850k Ram: rip jaws 32GBX4

submitted by /u/Raredisarray
[link] [comments]

Upgrading to Monterey: no signal after verbose

I'm working on a Dell T30 (E3-1225v5, P530 iGPU). Followed https://github.com/cstrouse/Dell-PowerEdge-T30-Hackintosh but too many things are broken now. Basically I updated BIOS to 1.8.1 and started over using OC 0.8.0. After 3 days I finally made everything perfect on Big Sur 11.6.5.

However when I try to install Monterey 12.3.1 I got no signal after verbose.

boot-args:

-v keepsyms=1 debug=0x100 npci=0x2000 alcid=3 igfxonln=1

iGPU injection:

AAPL,ig-platform-id 00001219
framebuffer-patch-enable 01000000
framebuffer-stolenmem 00003001
framebuffer-fbmem 00009000
device-id 1B190000
hda-gfx onboard-1

Any ideas?

submitted by /u/United-Layer-5405
[link] [comments]

status of HD 4600 on monterey? still glitchy?

Hello Everyone

i've got a haswell laptop , tried monterey on it , while everything went well , followed the opencore haswell laptop guide , the os was so smooth on the first boot but after i restarted the hardware accel got disabled (tried to fix it but it is not possible) and the system became so glitchy and laggy , like it was so unbearable , here are my specs

CPU : Haswell QuadCore Intel Core i7-4700MQ, 3.2 GHZ

integrated Intel HD Graphics 4600

8 GB RAM , 1600 mhz

Dedciated GPU : AMD Radeon R7 M265 (Opal)

Samsung SyncMaster S24D332 (HDMI) external monitor

submitted by /u/Capitorin
[link] [comments]

My Big Sur 11.6.6 wants to update to 11.6.6...

My Big Sur 11.6.6 wants to update to 11.6.6...

Not sure what is happening here. Should I reinstall the update? AMD system using macPro 7.1 profile.

https://preview.redd.it/dbhj1zrch6w81.png?width=1400&format=png&auto=webp&s=2f25faec5f827fc5925c5f5e86311b3940083550

submitted by /u/wingdingfingerling
[link] [comments]

Stuck on boot for Monterey on Optiplex 7050

Intel i7 7700 CPU

I followed the Opencore guide but am getting stuck on booting to the installation.

It gets past the initial boot but then gets hung up on the linked screenshot.

I can’t find anything on vm_shared_region_start_address() failed and not much on KernelEventAgent[212], dfrRecoveryd[195] or distnoted[210] saying No such process

Any assistance is greatly appreciated.

Error screen

submitted by /u/teh-reflex
[link] [comments]

Opencore EFI problem with Acer Veriton N4640G USFF system (i5-6500t H110 based)

Hello to the community
I have a weird issue where I couldn´t pass almost half-way of the loading bar (Opencore afa bootloader was showing up fine and would boot into other OSes but not MacOS) and I realised I had installed the release version of OC so I tried to replace the files with the debug version and after that it showed up only one time on boot menu, choose it and gave some text very quickly (probably just a few miliseconds on the screen, I didn´t have even have time to realise what...

Read more

Author: TurboPablo

Big Sur Success on MSI mpg z490 gaming plus but I've problems with acceleration on gtx 780

MSI MPG Z490-Gaming Plus
Intel Core i5-10600K
Open Core 0.8.0
MacOS 11.6.5 Big Sur
Corsair Vengeance 2x8 gb DDR4 2666 Mhz

with success but I have problems with gtx 780 3 gb Acceleration is not activated

NVIDIA GeForce GTX 780:

Modello Chipset: NVIDIA GeForce GTX 780
Tipo: GPU
Bus: PCIe
Slot: Slot-1
Larghezza canale PCIe: x16
VRAM (totale): 3 GB
Fornitore: NVIDIA (0x10de)
ID dispositivo: 0x1004
ID revisione: 0x00a1...

Read more

Author: zilath

macOs Big Sur on Dell Optiplex 3080 Micro

Hi everyone,

I'm trying to install BigSur on my Dell Optiplex 3080 Micro
- CPU: Intel Core i5 10500T
- RAM: 32Go 2400Mhz DDR4
- GFX: Intel 630 Graphics
- Drice: M2 Crucial 2080 1Tb

I have successufly installed BigSur, boot OK

Works:
  • Wifi (Intel 8265)
  • 2 x DP port
  • 2 x Back USB2 ports
  • 1 of the 2 front USB3 port (left one)
  • Ethernet (RTL8168)
Not working:
  • Bluetooth
  • Front (right) USB3
  • 2 x back USB3
  • Audio (Input/Output) ALC3246

For the audio part, i...

Read more

Author: Inglat

Share with you the Hackintosh Monterey full install

Share with you the Hackintosh Monterey full install, Anyone who uses the same configuration of Zbook 15 g2, please download and fix it a bit if your hardware is a bit different If not, just put it in and eat it, and anyone who uses Dell Precison M4800, fix it a bit in Config.

The current version is 12.3.1 built by myself, if you like it, please download and play, full set of fix installation full all.

Link to download the installer:



AMD Radeon RX 550 - 560 injected with Opencore macOS Big Sur

I have installed macOS Big Sur in a HP prodesk 400 G1 SSF. everything works for me, except the AMD Radeon RX 550 4GB graphics card, because I don't know how to inject into the OpenCore device properties section.When I was using Clover, it was easy because with fakepciid.kext was injecting the EDID + ati + radeonint + fake pci id ... but with OpenCore, I can't manage to inject these properties ... can someone help me?

Author: alejita27

Gigabyte Z390 Aorus Master with Radeon RX 6900 XT

Hi all I was hoping if any one could help us out my old 1080 ti ftw3 died on me the other day as I was working on my computer forcing me pretty much what I didn't want to spend to up grade to a 6900 XT that iv just got.

Could any one possibly help us out and post a working efi/opencore set up as I would need to borrow some ones laptop to sort it out, so that I can pretty much do a swap and a upgrade and updated to a new OS to get back what I need to finish asap please.

I am running a i9...

Read more

Author: merkle
